您好, 歡迎來到中國儀表網 登錄注冊產品展廳收藏該商鋪

上海科石科技發展有限公司 上海科石科技發展有限公司
1
當前位置:
上海科石科技發展有限公司>sf6檢測設備>sf6定量檢漏儀> lf-301定量檢漏儀高精度、便攜式、無易損件、無輻射源、sf6定量檢漏儀

在線溝通:

高精度、便攜式、無易損件、無輻射源、sf6定量檢漏儀

高精度、便攜式、無易損件、無輻射源、sf6定量檢漏儀
產品型號:lf-301定量檢漏儀
廠商性質:生產商
所  在  地:上海市
更新時間:2017-03-15 19:55:02
瀏覽次數:145

產品簡介
測試范圍 0.01-1000PPM 測量時間 1Ss
測量精度 0.01PPM 電源電壓 AC220或鋰電直流V
適應范圍 0.01-1000PPM
科斯達 上海科石科技發展有限公司
高精度、便攜式、無易損件、無輻射源、sf6定量檢漏儀,交直流兩用,替代進口
國內zui高精度氟類介質氣體微量分析儀
zui高精度0.01PPM;
科斯達檢漏儀被SGS檢測選用為檢測基準工具;
SGS是目前全球公認的zui權威國際檢測機構;
詳細介紹

高精度、便攜式、無易損件、無輻射源、交直流兩用sf6定量檢漏儀

替代進口SF6定量檢漏儀

Lf-301  SF6 quantitative detector

On the principle of high frequency magnetic field research and development, the low-voltage high frequency mode of ionization, product without radiation source, safe, reliable and durable

Adopt the touch screen control and display, the PPM concentration display, accurate quantitative 0.001ppm;

The simple user calibration function;

To prevent "poisoning" oil pollution and dust detector; no wearing parts, daily use and maintenance cost is very low;

auto detection of vacuum degree and judge the boot environment, automatically open the detector "fool" mode of operation; open the vacuum pump 5 minutes or so, the detector automatically enter the open state;

Schematic point of specific fault detection, simple and quick judgment equipment is normal or not and whether the user correct use, and simple fault elimination methods, effectively reduce the after-sales service, for the convenience of customers;

The vacuum pump is more stable gas flow rate and vacuum degree, the detection data is more stable, better repeatability, consistency;

important device adopts imported, according to aerospace, military requirements; meet in more than 95% of high humidity and ultra wide environment temperature: - 20 degrees to 50 degrees.

The outer packing with metal crash box design, easy to carry on site use;

高精度、便攜式、無易損件、無輻射源、sf6定量檢漏儀The product warranty for 3 years;

Product image





Technical parameters:高精度、便攜式、無易損件、無輻射源、sf6定量檢漏儀

Project

Lf-301 SF6 quantitative leak detector

Principle

high frequency magnetic field

Sensitivity

0.001PPm

"Poisoning" recovery time

less than 10 seconds in 99.99% under the environment of SF6

1 second, in the 10% SF6 environment

The response time

less than 0.5 seconds, 10ppm

less than 1 second, 1ppm

Indicating way

Detector LCD digital display: the greater the leakage concentration, the greater the number of changes;

Buzzer tip: the greater the leakage concentration, the greater the buzzer sound frequency

Integrated detector gas hose

3m

Power input line

2m

Input source

220V±22V 50Hz±2Hz

Ambient temperature

-20℃-50℃

Ambient humidity

less than 95%

Power

180-220W

Gross weight

Detector 1.2Kg

Host 7.1Kg

Host size

310×168×200mm

Outer package

Aluminum alloy collision avoidance box

Crash box weight

3.0Kg

Crash proof box

370*320*270

科斯達  上海科石科技發展有限公司
,交直流兩用,替代進口
國內zui高精度氟類介質氣體微量分析儀
zui高精度0.01PPM;
 科斯達檢漏儀被SGS檢測選用為檢測基準工具;
